5MP POE Mini IP Camera, Built in Microphone, UltraHD Indoor Small Security Camera with Audio, 3.6mm Lens(75° FOV), H.265/H.264, Smart Phone/PC App (I706-P-A)

Product description

REVODATA 5MP HD 2880 x 1620P Indoor Mental Mini Security Camera with Audio

Standard Security Camera design, support power from PoE switch, 5MP resolution give better image quality and more details compare with other Mini Surveillance camera

Metal case is more durable than plastic case.

Note:

1. This camera support both 48V PoE and DC 12V Power connection, you can choose to powered it with 802.3af 48V POE Switch or DC 12V/2A power adapter (Not Inculed).

2. This camera default 5MP & H.265, if your NVR do not support 5MP or H.265, you can change our camera into 1080P (2MP) and H.264 to fit the NVR

3. Due to the mini size, the camera will create more heat and it is safe and normal, don’t worry.

5 Mega-pixel 2880 x 1620P image quality

Equipped With 5 Mega-pixel 2880 x 1620P chips and a high performance CMOS sensor, image is more clear with more details compare with 2MP/3MP/4MP camera,would not missing any details anymore.

Built in Microphone(One-Way Audio)

Listen to what matters most using the built-in microphone for one-way audio.

Audio:

Monitoring range: 0-30 square metersSensitivity: 36dBSignal to noise ratio: 58dBPointing characteristics: omnidirectionalMicrophone size: φ6mm*5mm

Human detection and alarm

Once the camera detect humanoid movement,the notification will send to your phone or NVR or software immediately.

Advanced H.265 encode

With advance H.265 encode,only need half bandwidth and half storage space when transmit the same image compare with H.264

Sharing with family or friends

The camera supports sharing function, you can share it with family and friends so they can also view the camera with real time picture.

Good compatibility

The camera supports Onvif, therefore it can work with NVR/third party software by Onvif

Add to Cart

Customer Reviews

3.6 out of 5 stars 59

3.6 out of 5 stars 59

3.6 out of 5 stars 59

Price

$40.59$40.59
— no data

— no data

Resolution
5MP(2880 x 1620P) 5MP(2880 x 1620P) 5MP(2880 x 1620P)

Viewing Angle
75° 70° 180°

Focal Length
3.6mm Lens 3.7mm Pinhole Lens 1.7mm fisheye Lens

Audio
1-Way Audio with Built-in Mic 1-Way Audio with Built-in Mic 1-Way Audio with Built-in Mic

Dimension
5.3 x 4.5 x 4cm（2.09 x 1.77 x 1.57in) 5.3 x 4.5 x 4cm（2.09 x 1.77 x 1.57in) 5.3 x 4.5 x 4cm（2.09 x 1.77 x 1.57in)

Weight
0.2kg（0.44Ib) 0.2kg（0.44Ib) 0.2kg（0.44Ib)

Material
Metal Metal Metal

Storage
NVR or Computer NVR or Computer NVR or Computer

Power Supply
48V POE or DC 12V 48V POE or DC 12V 48V POE or DC 12V

Compression Format
H.265/H.264 H.265/H.264 H.265/H.264

Specification

Image Sensor: 1/3” CMOS Sensor (FH8852V310+GC5063) Frame rate： 20fps Min illumination: 0.1Lux @(F1.2,AGC ON) Shutter: 1/25 seconds -1/100,000 seconds IP address: Static (Default 192.168.1.108) / Dynamic Alarm: Motion detection, Email alarm Support Protocol: HTTP, TCP/IP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS, PPPoE, NTP System Support: Windows, iOS, Android O NVIIF Port: 8088 Operating Temperature: -25°C~60°C Operating Humidity: 10%~90% General function: A key recovery,dual stream,password protection,video hiding Ethernet: 10M/100M mbps Ethernet (RJ-45) Compression Rate Output: 128 Kbps~8Mbps Default user name: admin Default password: admin123

【UlatraHD 5MP Quality】CMOS 1/3” Image Sensor & 5.0 Megapixel (2880 x 1620P) at 20 fps, make a clear and smooth images/videos with more details.
【Support 48V 802.3af POE Function】Support POE function(Power Over Ethernet), connect to POE Swtich with only Cat5/6 cable, reduce the trouble of cable arrangement. And it also have auxiliary power connector, can be powered by a conventional 12V 2A power supply and used as a Non-POE IP camera.
【Mini Size IP Camera】This ip camera is tiny size with 5.3 x 4.5 x 4 cm and equipped with a camera stand, it can be easily installed in places where others will not notice.
【3.6mm Lens】 The 3.6mm lens fixed lens on this camera offers 75° view angle to cover and protect your area, you can clearly see the room/space via this camera.
【Service】We have app for smartphone available on app store, and VMS software for Windows (Can’t work with MAC OS or Linux).
