60W Gigabit PoE++ Injector – 10/100/1000Mbps, RJ-45 Shielded, IEEE 802.3af/at/bt Compliant, PoE Switch Powerline Network Adapter for High Power Ethernet Devices, Up to (328 FT) 100M

Product description

Gigabit PoE Ports Ensure Faster Connections

Both The Gigabit 10/100/1000 Input and Output Port Ensure Faster, More Reliable Connections for All Applications.

Fanless Design Reduces Power Consumption And Works Silently In Its Location, Making It Ideal For Noise-Sensitive Environments.

Compatible with PoE / PoE+ and PoE++ Devices

Easier Network Deployment,Higher Power Supply

PoE Injector++ Simultaneously Transmits Data and Powers a Standard PoE Device (60W Max.) Through One Ethernet Cable, Ideal for Surveillance, Wi-Fi Coverage, and More Applications.

The PoE Injector is a single port PoE injector offer a compact and cost effective, It can convert standard 100~240V/AC power into lowvoltage. DC that runs over existing LAN cable to power up IEEE 802.3af&at&bt compliant network accessories.

Surveillance Networksafe Enough To Usefor Any Security Needs

Remote powering of wireless LAN(WAN) access points, IP Security cameras, VoIP telephone and other low port density installations.

Works With Ip Cameras For Home And Office, Small Business

The PoE Injector PoE Mid-spans eliminate the need for external power supply and its associated AC/DC power cabling, providing a compact, affordable, safe and reliable power solution over existing Ethernet infrastructure.office network functional to use in any size office

Product Specification

Data Transfer Rate 10/100/1000Mbps Pin Assignment and Polarity 1/2(-)3/6(+),4/5(+)7/8(-) Output Power Voltage: 54VDC User Port Power: 30W&60W AC Input Voltage 100 to 240 Vac AC Input Current 1A 100~240V System indicator AC Power Connectors Shielded RJ-45, EIA 568A and 568B Operating Ambient Temperature 0 to 40℃ Storage Temperature -10 to 50℃ Supporting Devices PoE/PoE+/PoE++ User Indicator Channel Power

Is the POE passive or active?

This POE is an active power supply.

Can I use a PoE injector with my PoE wifi?

Yes, it can work for all PoE devices below 60W.

Are the lights the same color when the PoE is powered on and when it is loaded?

The PoE injector lights up green when powered on and lights up blue when it is loaded.

Can this 60W PoE injector power my 30W PoE WIFI?

Of course, this 60W PoE injector is 48V standard IEEE 802.3bt, 30W is of course no problem.

Can this device power a 60W extender, which in turn powers four 15W PoE cameras?

Yes, it can, as long as it conforms to the standard protocol.

Experience Lightning-Fast Gigabit Speed: With 1 input port and 1 PoE++ gigabit ethernet output port, this injector delivers up to 2Gbps full duplex ethernet speeds, ensuring you never have to compromise on speed
Compatible with Various Devices: The unit is designed to work with both 802.3af PoE (15.4W) and 802.3at PoE+ (30W) devices, and offers backwards compatibility for passive PoE devices. It can deliver up to 802.3bt 60W to PoE++ devices
Safe and Reliable Power Delivery: Our injector can automatically detect PoE and non-PoE equipment, providing compliant equipment with the appropriate power and automatically powering off non-standard PoE equipment to protect it
Hassle-Free Installation: This unit has an internal AC/DC converter, eliminating the need for an external power brick, and is plug-and-play for easy installation. LED power indicators and PoE output make usage straightforward, perfect for most installation scenarios
Effortless Network Extension: With this injector, you can convert a non-PoE Gigabit port to a PoE++ Gigabit port and extend your network up to 100 meters away, making network extension an effortless process
Safer and Easier Maintenance: Our unit’s weak current wiring guarantees a safe and secure project, while the follow-up maintenance equipment is simpler and more straightforward. Keep your equipment running smoothly without any hassle
