ELECROW WiFi HaLow Gateway – ThinkNode G4 WiFi HaLow Bridge 802.11ah | Support Wi-Fi/Wi-Fi HaLow/Ethernet Connections, Ideal for Robotics, Industrial Control, Smart Home, IoT Applications, 915 MHz

Product description

Specifications of ThinkNode G4 WiFi HaLow Gateway

CPU/SoC HLK-7628N Module System memory DDR2128MB Storage 32MB Chip FGH100M WiFi Protocol IEEE 802.11ah WiFi Band 850~950 MHz Wifi Modulation Method OFDM/ BPSK/ QPSK/ 16QAM/ 64QAM Encryption mode AES, SHA-256, SHA-384, SHA-512, WPA3 Work mode AP/ STA / Mesh Physical layer maximum rate 802.11ah: 32.5 Mbps Maximum output power 21dbm WiFi Supports 802.11 b/g/n protocols (2.4 GHz band), with a maximum speed of 300 Mbps Ethernet Up to 100 Mbps per port, supports switch functionality. Encryption Method WEP64/128, TKIP, AES, WPA, WPA2, WAPI Interface Type-C Interface, Ethernet Port, WiFi HaLow Antenna Interface, WiFi Antenna Interface Power supply voltage Typical 5.0 V-1A

Long-Range Wi-Fi HaLow Connectivity: Powered by IEEE 802.11ah Wi-Fi HaLow technology, this gateway operates in the Sub-1GHz band to deliver reliable long-range wireless communication with a theoretical range of over 1 km. Compared with traditional Wi-Fi, it provides extended coverage and improved resistance to interference for stable IoT connectivity
Dual-Band Flexible Networking: Equipped with a high-performance MCU and advanced RF front end, this Wi-Fi HaLow gateway supports both Wi-Fi HaLow and 2.4GHz Wi-Fi, with a Ethernet port for seamless integration into existing networks. AP, STA, and Mesh modes enable flexible network deployment for diverse IoT applications
Reliable Performance and Secure Networking: Supports WPA3 security and multiple encryption methods to help protect wireless communications. Designed for low-power operation and continuous performance, this gateway works reliably in environments with an industrial operating temperature range of -20°C to 70°C (-4°F to 158°F)
Simple Deployment and Remote Maintenance: Configure and monitor the gateway through an intuitive browser-based Web UI without complicated software installation. OTA firmware updates simplify maintenance, while support for remote management helps reduce deployment time and keeps large-scale IoT networks running efficiently
Designed for Diverse IoT Applications: Designed to connect a large number of wireless devices through a single gateway. Supports WPA3 and multiple encryption methods for secure communication, making it well suited for smart cities, manufacturing, security monitoring, rural networking, and enterprise IoT infrastructure
