MINISFORUM N5 Air 5-Bay Desktop NAS with up to 174 GB Storage, AMD Ryzen 7 255 (8C/16T) CPU, Dual DDR5 RAM Slots (up to 96 GB), 1x 10GbE, 1x 5GbE, 2X USB4 (8K), HDMI 8K, OCuLink, 3X M.2 Slots

Product description

1 Processor

2 GPU

3 2 DDR5 Slots

4 PCIe x16 Slot

5 Oculink for eGPU

1 Pro Player

2 Shared Data

3 Faster & Safer

4 Media Hub

1 Various RAID Modes

2 Access Control

3 Remote Access

4 Docker Container

5 Sync & Data Backup

1 MinisCloud OS

2 Improved Experience

3 Extensive Interface

4 Triple Display

【Processor AMD Ryzen 7 255】: MINISFORUM N5 Air desktop NAS is equiped AMD Ryzen 7 255 (8 cores, 16 threads, up to 4.9GHz) with AMD Radeon 780M graphics (12 core 2600MHz). Supports multi-user access, simultaneous multi-file retrieval, and ultra-high-speed audio/video decoding. Replace slow traditional hard drive workflows with a centralized data management center offering centralized storage, automatic backup, remote access, and rich RAID options.
【174TB Massive Storage Capacity】: With five SATA HDD slots supporting up to 174TB, NAS N5 Air offers vast storage potential. Customize your storage configurations with a mix of M.2 NVMe SSDs to suit both your active and archival data needs effectively. The N5 Air comes pre-installed with a 64GB SSD for MinisCloud OS. For users requiring more customization, easily replace the system disk for alternative setups while retaining the flexibility to use a USB flash drive for installation.
【Rich Extensions】：MINISFORUM N5 Air NAS features 2x DDR5 SO-DIMM slots, which can be expanded up to 96GB (up to 48GB per slot). It has dual USB4 ports, supporting data transfer rates of up to 20Gbps. Utilize the PCIe ×16 slot for additional expansions such as high-speed NICs and GPUs, realize ultra-low latency storage. Boost read/write speeds without replacing your system—plug and play.
【Triple 8K Video Outputs】: The MINISFORUM NAS N5 Air expand your workspace with the ability to connect up to three displays simultaneously via 1x HDMI (8K@60Hz/4K@144Hz) and 2x USB4 (8K@60Hz/4K@144Hz) Ports. Elevate your productivity by managing multiple tasks and applications across a larger visual landscape.
【Rapid Networking Speeds】: Equipped with dual LAN ports—10GbE and 5GbE—the N5 Air supports link aggregation for astonishing transfer speeds of up to 15Gbps. Perfect for team collaborations and handling large files simultaneously across various users.
【MinisCloud OS, All-in-One APP】 — MinisCloud OS supports Windows, macOS, iOS, and Android with a minimal learning curve. Built-in features: ZFS snapshots, LZ4 compression, multi-user isolation, Docker apps, AI photo albums, and one-click remote access—fully managed and ready to use.
【Advanced OCuLink Interface】: Connect external PCI Express devices with the native OCuLink interface, achieving unparalleled speeds of PCIe4.0 x4=64G. Enhance your computing with external graphics cards or specialized AI hardware for cutting-edge performance.Note: This interface does not support hot-swapping.
【Robust RAID Options】: Protect your data with multiple RAID configurations, including Raid0, Raid1, and Raid5/RaidZ1. The N5 Air provides tailored solutions for data security and speed, ensuring that you have peace of mind while maximizing performance.
【Innovative Modular Design】: Minisforum’s slide-out motherboard enables quick RAM and SSD upgrades for simplified maintenance. Modular design uses standard RAM (no onboard limits). Dual 9025 large axial fans actively cool HDD bays for stable operation. Compact 199×202×252mm frame fits 5 drives in a 4-bay footprint, delivering 25% more storage.
【System Disk & Installation Note】： MINISFORUM N5 Air ships with MinisCloud OS installed on the built-in 64GB SSD. The system disk occupies one of the three M.2 SSD slots. To use all three M.2 slots, uninstall the system disk and install a third-party OS via a USB flash drive in the internal USB port, but doing so removes MinisCloud OS and related functions.
