MINISFORUM N5 Pro 5-Bay Desktop AI NAS, AMD Ryzen AI 9 HX PRO 370 12-Core/24T CPU, 128GB SSD, 1x10GbE, 1x5GbE, 1xM.2+2xU.2/M.2 Slots, 2xUSB4(8K), 8K HDMI, OCuLink, Network Attached Storage (Diskless)

Product description

The video showcases the product in use.The video guides you through product setup.The video compares multiple products.The video shows the product being unpacked. MINISFORUM N5 Pro AI NAS, desktop AI NAS Merchant Video

Technical Specification N5 Pro AI NAS with AMD Ryzen AI 9 HX PRO 370 Processor

CPU AMD Ryzen AI 9 HX PRO 370 Processor, 4x Zen 5, 8x Zen 5c, 12 cores and 24 threads, up to 5.1GHz GPU AMD Radeon 890M NPU Up to 50 TOPS Overall TOPS Up to 80 TOPS Memory 2x DDR5 SO-DIMM slots (5600 MT/s), Expandable up to 96GB ECC Memory Storage 128GB M.2 2280 SSD (MinisCloud OS Preinstalled) lnternal Slot 5x 3.5/2.5 inch HDD(Up to 22TB/disk)(SATA 3.0); 1x U.2/M.2 2280/22110 NVME SSD(up to 15TB, PCIE4.0 x1); 1x U.2/M.2 2280/22110 NVME SSD(up to 15TB, PCIE4.0 x2); 1x M.2 2230/2280/22110 NVME SSD(up to 4TB, PCIE4.0 x1); 1x PCIe x16 Slot (PCIe 4.0 x4); Dual LAN Ports 10GbE LAN Port + 5GbE LAN Port OCulink Port Native OCulink Port, Can be connected to an external independent graphics card Video Output 2x USB4(Up to 8K@60Hz/4K@144Hz), 1x HDMI2.1 FRL(Up to 8K@60Hz/4K@144Hz) Audio Output 2x USB4, 1x HDMI2.1 FRL I/O Ports 2x USB4, 3x USB 3.2 Gen2, 1x HDMI2.1 FRL, 1x 10GbE LAN(RJ45,AQC113), 1x 5GbE LAN(RJ45,RTL8126), 1x OCulink Port, 1x USB 2.0, 1x PCIe ×16 Slot (PCIe 4.0 ×4) Power Adapter Input: 100-240V AC, Output: DC(5.5*2.5MM) 19V 14.7A 280W Package Included 1x N5 Pro NAS, 1x M.2 to U.2 Adapter Board, 1x US Power Adapter, 1x Power Cable, 1x HDMI Cable , 1x Network cable, 1x User Manual

1 Overall TOPS

2 AMD AI 9 HX PRO 370 CPU

3 2x DDR5 Slot(ECC Support)

4 Triple Video Output

5 OCuLink for External GPU

1 Ultra-Fast Network

2 PCIe x 16 Slot

3 Multiple RAID Modes

4 Slide-Out Design

5 Cooling System

1 MinisCloud OS System

2 LZ4 Compression

3 Local Account

4 Access Control

5 Rich Interface

Powerful AI Processor: MINISFORUM N5 Pro NAS has next-generation AI technology, AMD Ryzen AI 9 HX PRO 370 processor, Zen 5+Zen 5C architecture, up to 5.1GHz, 12 cores, 24 threads, up to 80 TOPS, bringing unprecedented high performance. Supports multi-user access and concurrent file retrieval, and delivers ultra-fast media decoding. With the support of AMD Radeon 890M, you can play your favorite AAA games with smooth, stunning graphics and zero latency.
5-Bay, 144TB Massive Data Storage: N5 Pro desktop AI NAS equipped with five SATA HDD slots: supports 22TB x 5, and 3x M.2 NVMe SSD slots or 1x M.2 NVMe SSD slot + 2x U.2 NVMe SSD slots: supports 4TB + 15TB + 15TB. Network Attached Storage for Video & Content Creators, maximum storage capacity of up to 144 TB. Multiple Raid modes for data security, supports Raid0, Raid1, Raid5/RaidZ1, Raid6/RaidZ2, and mixed drive strategies for hot data and cold backup, speeding reads and cutting storage costs.
10GbE+5GbE Network Ports: This AI NAS is equipped with 1x 10GbE high-speed network port and 1x 5GbE network port. 10G + 5G dual ports support link aggregation, delivering 15 Gbps speeds. 10GbE networking powers high-speed transfers for cross-team collaboration, large file handling, and parallel multitasking.
Expandable DDR5 ECC Memory: MINISFORUM N5 Pro AI NAS has a 2x DDR5 SO-DIMM slot (5600 MT/s), expandable up to 96GB ECC memory. Tailored for NAS applications to ensure maximum data reliability and system stability. ECC Error-Correcting memory technology automatically detects and corrects bit errors in memory, preventing system failures and data corruption, thus protecting vital business files. DDR5 5600 offers 75% more bandwidth than DDR4, ideal for high-concurrency and large file handling, supports more VMs, and provides smoother data. Combining reliability and performance, it’s ideal for both business and home use.
MinisCloud OS, All-in-One APP: MinisCloud OS seamlessly supports Windows, macOS, iOS, and Android with zero learning curve. Built-in features include ZFS snapshots, LZ4 compression, multi-user isolation, Docker apps, AI photo albums, and one-click remote access—fully managed, ready to use.
Innovative design: Minisforum’s slide-out motherboard allows quick RAM and SSD upgrades, simplifying maintenance. Modular design supports standard RAM, avoiding onboard limits for flexible upgrades. Dual 9025 large axial fans actively cool HDD bays, ensuring stable and cool operation at all times. A Compact 199×202×252mm frame holds 5 drives in a 4-bay space, delivering 25% more storage.
Support OCuLink Port: Our N5 Pro NAS is equipped with a native OCuLink interface. OCuLink is a standard for externally connecting PCI Express, the speed is PCIe4.0 x4=64G. With this port, you can connect to an external discrete graphics card to enhance gaming and AI capabilities, supporting faster speeds compared to Thunderbolt 4 and USB4. Note: This interface does not support hot-swapping.
8K Triple Video Outputs: This N5 Pro NAS is equipped with 1x HDMI (8K@60Hz/4K@144Hz) and 2x USB4 (8K@60Hz/4K@144Hz) Ports, allowing you to connect up to 3 displays simultaneously. Increase work efficiency by expanding multiple workspaces.
Rich Connectivity, Total Flexibility: N5 Pro NAS supports Dual USB4, each USB4 supports up to 20Gbps Thunderbolt Ethernet. PCIe ×16 slot supports 10GbE NICs, GPU expansion, and SSD cache arrays for ultra-low latency storage. Boost read/write speeds without upgrading your system—Plug and Play.
Note: MINISFORUM N5 & N5 Pro come with the NAS system MinisCloud OS, which is installed in the machine’s built-in 128GB SSD. The system disk has occupied one of the three M.2 SSD slots in the machine. If you need to use all three M.2 SSD slots, you need to uninstall the system disk yourself. You can use a third-party system using a USB flash drive to insert it into the machine’s internal USB port for installation and use. At the same time, you will no longer be able to use the MinisCloud OS system and related functions.
