PR10-E US15A Power Meter Plug/Home Power metering Socket/watt Meter/2.4 inch TFT Color LCD/0.5FS(New)

Product description

Product Overview

PR10 Power Recorder is displayed by 2.4 inch TFT color LCD, and it can measuring a variety of electrical equipment’s power, power factor, voltage, current, frequency, accumulated electricity consumption, accumulated electricity bill, accumulated electricity time, one shot electricity consumption, one shot electricity bill and one shot electricity time.Daily use of electricity and electricity bill will be recorded, you can see the form of a chart or list of historical records. PR10 is suitable for the measuring and monitor power consumption of the household, factory, office and other cases, and can be used to power on or power off a various electric equipment according your setting.

2.4 – inch true color TFT LCD display.0.5FS – level measuring accuracy.8 Languages UI can freely to be chosen.23 currency units can be set freely.Date and time can be set, 5 date formats are supported.Automatic record historical data, which can be review in the form of a list or chart.

Technical index

Precision Class 0.5% FS Rated Voltage AC85V~265V Power Rating Less than 2.5W Current Range 0.005A~15A Power Range 0.1~3750W@250V Energy Range 0~999999kWh Bill Range 0~999999 PF Range 0-1.0 Time Range 0-999 days

High quality material,High reliability,Preventing burning

High reliability switching power supply

Using high-reliability switching power supply, the input voltage range from AC85V to 265V.

Flame retarding materials

The plastic shell material is made of fire retardant material, Good flame retardant and anti impact performance, high strength.

Heat resistant silicone suture

The connection in the recorder is a high temperature resistant silicone wire with a cross-sectional area of 2.5 square millimeters, which has good flame retardancy and toughness.

High current relay

SANYOU 16A relay is used to improve the reliability of the system.

History records

Month-Chart

Month-List

Year-Chart

Year-List

PR10-E has 9 timers

Timer 1 and Timer 2 are advanced timers, which can be specifically set to power on or off at a specific time on weekdays or weekends or to light up or turn off the device at a specific time on a specific date.Timers 3 to 9 are general-purpose timers. They can be set to turn the power on and off at a certain time, but they cannot specify to turn on or off the power on a specific date.

Alarm and protection

It has an alarm function and can be set to trigger an alarm when the voltage, the current, the power or the temperature exceeds alarm settings.It has an output protection function and can be configured to cut off the power when the voltage, the current, the power or the temperature exceeds the output protection value.The alarm limit and the output protection limit can be freely set.

Add to Cart

Add to Cart

Add to Cart

Add to Cart

Customer Reviews

4.0 out of 5 stars 89

4.1 out of 5 stars 102

3.4 out of 5 stars 5

5.0 out of 5 stars 2

—

Price

— no data
$41.50$41.50 $57.00$57.00 $62.00$62.00 $61.00$61.00

Ground pin reversed New design Max 120A Max 120A with external relay With external temperature sensor

It has alarm function and can be set to alarm when the voltage, current, power or temperature exceeds alarm settings.
The total power consumption and historical records can be cleared or do the factory restore in the system setting page.
There are three main display pages: the overview page, the one shot electrical page and real-time electrical parameters page, the default page is overview page, users can press ” “key to switch different display page
Automatic record historical data, which can be review in the form of a list or chart, and can be stored for up to 30 years
