StoneStorm 4-Bay NAS Mini PC Dual 2.5GbE i226-v LAN Ports, 12th Gen. N150 with DDR5 MAX 48GB, 4 M.2 NVMe 2280, Dual 4K Display, 2 USB3.2 10Gbps for Micro Firewall Router/Pocket Computer (Barebone)

Product description

Highlights of N150 mini pc:

Mini Compact PC Can Even Fit in Your PocketRemovable Top Cover for Hard Disk Cooling, Pre-drilled 70mm*70mm Fan Locking HolesBuilt-in 4 M2 Adapter Board, support 4x M.2 NVMe 2280 size7010 Ball PMW Fan Aluminum Heat Sink with Copper PlateAll-aluminum Chassis with CNC CraftsmanshipBuilt-in M.2 B Key WiFi slot (NOT Included any wireless module)

If you need a user manual, please leave msg to the seller or visit our store FAQ page to download it.

CPU Intel Twin Lake N150 / N355 Optional RAM 1* SO-DIMM DDR5 4800MHz, Max 48GB SSD 4* M.2 2280 NVMe PCle3.0 x1 signaling Display 2* HDMI2.0 (support 4K 4096×2160@60Hz) Network 2* Intel i226-v 2.5GB USB 2* USB3.2 Gen2 10Gbps Wireless Technology M.2 B_Key slot, supports BT5.4 / WiFi6 / WiFi7 modules (NOT Included) Heat Dissipation Copper sheet heat conduction aluminum profile cooling, 7010 ball fan blades, PMW four-wire temperature control silent fan Size Case: 3.94 x 3.94 x 2.3 inch (100 x 100 x 58.5 mm); Mainboard: 3.54 x 3.54 inch (90 x 90 mm) BIOS AMI EFI BIOS, supports Auto-power-on, Wake-on-LAN, PXE Power Supply DC-IN 12V (55mm*25mm) OS Supports Windows 10, Windows 11, Linux, NAS, etc.

Dual HDMI2.0 Ports

Supports dual 4K display at 4096×2160@60Hz to give you a better visual experience

Dual USB3.2 Gen2 Ports

Supports 10Gbps transmission rate to enhance data transfer efficiency and user experience

Dual 2.5G LAN Ports

Supports OpenMediaVault/TrueNAS/Unraid…. .VMware/ESXi/PVE/Hyper-V…. Other systems

Fast Running Office Software

Supports quickly running of most office software to improve work efficiency

Meet the Needs of Various Application Scenarios

Add to Cart

Add to Cart

Add to Cart

Add to Cart

CPU
Intel N355 8-core 8-thread, up to 3.9GHz i3/i5/i7 12th/13th/14th Gen. desktop processors i3/i5/i7 12th/13th/14th Gen. desktop processors Intel N150 4-core 4-thread, up to 3.6GHz i3/i5/i7 12th/13th/14th Gen. desktop processors

RAM
1* DDR5 slot, up to 48GB 2* U-DIMM DDR5 slot, up to 64GB 4* U-DIMM DDR5 slot, up to 128GB (unbuffered-ECC RAM) 1* DDR5 slot, up to 48GB 4* U-DIMM DDR5 slot, up to 128GB

SSD
4* M.2 NVMe 2280 (PCIe3.0x1) 3* M.2 NVME (PCIe4.0x4) 2* M.2 NVME (PCIe4.0x4), 1* M.2 NVME (PCIe3.0x4) 2* M.2 NVMe 2280 (PCIe3.0x1) 2* M.2 NVME (PCIe4.0x4)

SATA
2* 12Pin JFPC SATA Socket 8* SATA3.0 by extension 12* SATA3.0 by extension 8* SATA3.0 by extension 12* SATA3.0 by extension

Display
2* HDMI 1* HDMI, 1* DP 2* HDMI, 2* DP, 1* Type-C 1* HDMI, 1* DP 1* HDMI, 1* DP, 1* VGA, 1* eDP

Network
2* i226-v 2.5GB 1* i226-LM 2.5GB (vPro), 1* i226-v 2.5GB 1* AQC113CS 10GB, 1* i226-LM 2.5GB (vPro), 1* i226-v 2.5GB 1* AQC113C 10GB, 2* i226-v 2.5GB 1* i226-LM 2.5GB (vPro), 2* i226-v 2.5GB

OS Support
Windows10, Windows11, Linux Windows10, Windows11, Linux Windows10, Windows11, Linux Windows10, Windows11, Linux Windows10, Windows11, Linux

Power Supply
12V 8A ATX 24pin + 8pin ATX 24pin + 8pin ATX 24pin + 4pin ATX 24pin + 8pin

Accessories
1* 12V 8A Power Supply, 1* HDD Screws & Feet Pads 1* I/O Shield, 2* SFF8643 Adapter Cable 1* I/O Shield, 3* SFF8643 Adapter Cable 1* I/O Shield, 2* SFF8643 Adapter Cable 1* I/O Shield, 3* SFF8643 Adapter Cable

Powerful Processor: This mini PC with high performance processor Intel N150 4 Core 4 Threads, 6MB Cache, up to 3.6GHz, and UHD Graphics. It supports Intel AES-NI, Auto-power-on, PXE, etc
Large Capacity: This compact pc comes with NO RAM NO SSD. It has 1 x DDR5 slot (It supports MAX RAM 48GB), 4 x M.2 NVMe 2280 PCIe3.0 x1 signal for 4-Bay NAS Applications. It’s compatible with Crucial RAM and top brand memory
2 x 2.5GbE LAN: This micro firewall appliance with 2 x i226-V network card chip. You can use it for home/business daily working/soft routing/network security firewall software, edge computing and hypervisor applications, etc
High Connectivity: This compact pc supports 24/7 hours quiet running and it has 2 x LAN, 2 x USB3.2 Gen2 10Gbps, 2 x HDMI(4096*2160@60Hz) which can support dual screen display(Duplicate mode, Extend mode) to improve your working efficience
Packing List: 1 x StoneStorm 4-Bay NAS PC, 1 x 12V 5A Power Supply, 1 x HDD screws&feet pads. For user manual, please leave a msg to the seller.
