ZigBee 3.0 Ripple Fold Smart Curtain Track System – Motorized Wave Drapery Rods, Automatic Electric S-Fold Rail with Remote, 1.8N.m Heavy Duty, Compatible with Alexa. (4 meters (157.4 inches))

Experience the Elegance of Ripple Fold Automation
Upgrade your window treatments with the SX-GM46T ZigBee Smart Ripple Fold Curtain Track System. Distinct from traditional rods, this system is engineered specifically for the Ripple Fold (also known as S-Fold or Wave Fold) style. The specialized runners keep your fabric in soft, continuous waves, delivering that coveted “floating” look found in high-end hotels. Combined with ZigBee 3.0 stability, it offers the perfect blend of modern aesthetics and smart home performance.
Technical Specifications:
Model: SX-GM46T
Track Style: Ripple Fold / Wave Fold / S-Fold
Connectivity: ZigBee 3.0 (Requires a ZigBee Gateway/Hub)
Charging Voltage: 100~240V/AC @ 50/60Hz
Rated Power: 18W
Rated Torque: 1.8N.m
Rated Current: 0.08A
Running Speed: 14cm/s
Protection Class: IP41
Motor Dimensions: 71x46x285mm (2.8×1.81×11.22 inch)
Installation Method: Ceiling Mount (Standard)
Track Material: Aluminum Alloy (1.3mm wall thickness)
Belt Structure: Built-in 8 steel wires
Exclusive Customization Services:
We know one size does not fit all. We offer tailored solutions to match your specific interior design:
1. Length: Custom sizing available for any length between 1 to 10 meters.
2. Installation: Wall mounting brackets available upon request (Default is Ceiling Mount).
3. Opening Direction: Customizable for Single-Side opening (Left-to-Right or Right-to-Left). Default is Center Opening.
4. Track Shape: 90° or 135° curved tracks available for bay windows. Default is Straight Track.
Frequently Asked Questions (Q&A):
Q: What kind of curtains do I need for this track?
A: This track is designed for Ripple Fold (S-Fold) curtains. Please ensure your drapes are sewn with snap tape or are specifically made for ripple fold runners, not pinch pleats or grommets.
Q: Do I need a Hub for this curtain motor?
A: Yes. This is a ZigBee 3.0 device. It requires a compatible ZigBee Gateway/Hub (not included) to connect to the App and voice assistants.
Q: Can I control different curtains separately with the included remote?
A: No. The included remote is a single-channel controller designed for “Group Control.” You can pair up to 15 motors to this one remote, but they will all open or close together simultaneously.
Q: Is the track difficult to assemble?
A: Not at all. We ship the track in pre-assembled segments. You only need to connect the segments and tighten 4 screws.
【HOTEL-STYLE RIPPLE FOLD AESTHETIC】 Transform your home into a luxury suite with our specialized Ripple Fold (S-Fold) system. Unlike standard pinch pleat tracks that look cluttered, our track runners are interconnected to force the fabric into perfectly uniform, continuous waves. This “Snake Fold” design creates a clean, modern, and high-end drapery flow that stays consistent every time you open or close them.
【ASSEMBLED FOR SIMPLICITY】 Stop struggling with “puzzle-like” tracks. Unlike competitors that arrive in confusing fragments, our Ripple Fold track segments are pre-assembled. Simply align the joiners and tighten 4 screws to complete the setup. We solved the installation nightmare so you can enjoy professional-grade automation in minutes, not days.
【TECHNICAL DATA】 Model: SX-GM46T | Track Type: Ripple Fold (Wave/S-Fold) | Protocol: ZigBee 3.0 (Gateway Hub Required) | Torque: 1.8N.m | Power: 18W | Speed: 14cm/s | Voltage: 100-240V/AC | Load: 100kg | Protection: IP41 | Size: 2.8×1.81×11.22 inch. Built for high-stability smart home integration.
【APP CONTROL VIA ZIGBEE HUB】 Connect to your ZigBee 3.0 gateway (sold separately) to unlock full control via the Smart Life/Tuya App. Whether you are at the office or traveling, you can check your wave curtains’ status and operate them remotely. ZigBee connectivity ensures a stable signal that won’t congest your home Wi-Fi network, providing faster response times than standard connections.
【HANDS-FREE VOICE COMMANDS】 Seamlessly compatible with Amazon Alexa and Google Assistant (via a compatible Hub). Just speak a simple command to let the light in or create a movie theater atmosphere. Perfect for moments when your hands are full with cooking, children, or laundry.
【UNIFIED GROUP REMOTE CONTROL】 Includes a 433.92MHz single-channel remote designed for synchronized management. While it is a single-channel controller, it can pair with up to 15 different motors simultaneously. Press one button, and all paired wave curtains in your living room or bedroom will glide open or closed in perfect unison.
【AUTOMATED SCHEDULING】 Set it and forget it. Customize weekly schedules to fit your lifestyle. The motor can automatically operate based on specific times or sync with local sunrise and sunset data. This feature ensures your plants get sunlight and your furniture is protected from harsh UV rays without you lifting a finger.
【SMART OBSTACLE & MANUAL FEATURES】 Designed with safety in mind. If the curtain encounters an obstacle during operation, it stops immediately to protect children, pets, and the fabric. It also features “Touch Motion”—gently pull the curtain 10cm to trigger automatic movement. In the event of a power outage, the clutch disengages, allowing full manual operation.
【INTELLIGENT SCENE LINKAGE】 Leverage the power of ZigBee 3.0 to create a truly interconnected home. Link this motor with other smart sensors (like door sensors or light bulbs) to create complex scenes. For example, automatically close the drapes when the smart lights turn on for “Cinema Mode” or when you leave the house.
【HEAVY-DUTY SILENT PERFORMANCE】 Engineered for luxury and durability. The motor operates at a whisper-quiet level (below 38dB). The 1.3mm thick aluminum track and belt with 8 embedded steel wires support a massive 100kg load. Driven by a 1.8N.m motor, it handles heavy velvet or blackout ripple fold drapes effortlessly. Backed by a 5-Year Warranty.
